Introducing the PJSIPNotify dialplan application

The ability to send SIP NOTIFY messages to endpoints and arbitrary uri’s via AMI and CLI has existed for some time within Asterisk.  Changes from a recent CommUnity UCaaS submission have expanded these capabilities.

This starts with including the ability to send NOTIFY messages within the current SIP dialog for a channel.   Previously, manual NOTIFY messages could only be sent to an endpoint or uri.

The CLI command pjsip send notify was added to include this capability.  The new syntax is as follows:

pjsip send notify [option] [channel | endpoint | uri] [destination]

More importantly, this capability has now been extended to a new dialplan application PJSIPNotify.  The PJSIPNotify application can send either a pre-configured set of headers (read from one of the entries in pjsip_notify.conf) or as a list of headers specified in dialplan to either a specified uri or within the current SIP dialog for the channel.

Let’s take a look at a few dialplan examples and what the resulting NOTIFY looks like.

The following dialplan:

same => n,PJSIPNotify(,&Event=Test&X-Data=Fun)

Results in the following headers being sent within an in-dialog NOTIFY message:

X-Data: Fun
Event: Test

To send a NOTIFY with the same headers to <sip:[email protected]:5260>, specify the uri:

same => n,PJSIPNotify(<sip:[email protected]:5260>,&Event=Test&X-Data=Fun)

The message body can also be set either in dialplan itself:

same => n,PJSIPNotify(,&Event=PotatoReport&Content-type=application/potato-summary&Content=Num-Potatoes: 23&Content=Potato-Quality: fair&Content=)

or via pre-configured entry in pjsip_notify.conf:

same => n,PJSIPNotify(,potato-notify)

[potato-notify]
Event=>PotatoReport
Content-type=>application/potato-summary
Content=>Num-Potatoes: 23
Content=>Potato-Quality: fair
Content=>

Both of these will result in the same headers and body:

Event: PotatoReport
Content-Type: application/potato-summary
Content-Length: 38

Potato-Quality: fair
Num-Potatoes: 23

Please note that in order to use this feature to send a NOTIFY to an arbitrary uri, you need to make sure that default_outbound_endpoint in your global pjsip settings points to a valid configured endpoint.
